4442 card

Product Details:

Material: PVC, PET, PET-G, PC
Size: CR80 standard 86*54mm
Printing: Blank Card or Customized Printing
Thickness: 0.81mm
Chip: Fuda FM4442
Interface: Contact only.
Protocol: ISO7816
EEPROM: 256 Byte
Function: Read & Write
Compatible Chip: Infineon SLE4442 SLE5542
Lifetime: >100,000 times read & write. >8 years
Applications: Membership Card, Hotel Key Card, Fuel card, Cashless Payment Card, Game Card, Access control card, Public Transportation Card, etc.”

Description

Over View:

The Fudan FM4442 consists of 256*8 bits of EEPROM main memory and a 32-bit protection memory with PROM functionality. The main memory is erased and written byte by byte. Each of the first 32 bytes can be irreversibly protected against data change by writing the corresponding bit in the protection memory. It has the same address as the data byte in the main memory to which it is assigned. Once written, the protection bit cannot be erased (PROM).



Application areas:

Membership Card, Hotel Key Card, Fuel card, Cashless Payment Card, Game Card, Access control card, Public Transportation Card, etc.
